Prop Sleeve
A Prop Sleeve keeps adjustable steel props working smoothly on construction sites. It allows fast height control, secure locking, and steady vertical load support in formwork and scaffolding systems. When props carry the weight of entire slab structures, this sleeve helps them stay stable and safe.
Prop Sleeve -Built for Strength and Daily Site Performance
We manufacture the sleeve using high-quality steel and precision-cut MC 4 TPI threading. Therefore, the nut moves freely on the prop without sticking and locks firmly when you tighten it. It fits 60.3mm OD prop tubes, which means it works perfectly with most adjustable props used in residential towers, industrial sheds, and bridge projects.
Prop Sleeve-Versions That Match Project Load Needs
Every project has a different load requirement. So, we offer three thickness options:
-
2.9mm
-
3.0mm
-
3.2mm
Choose the one that gives you the safety margin your site demands. Each sleeve includes a 150mm × 12mm welded handle, giving workers quick control while raising or lowering props under load.
Tough Finishes for Longer Life
Contractors often deal with weather, concrete spills, and nonstop movement. Because of that, the sleeve is available in:
-
Zinc Plated for corrosion resistance
-
Self Finish for easy coating or direct use
Both finishes help the sleeve stay reliable throughout repeated cycles on site.
Where It Works Best
You will see this sleeve in:
-
Slab and beam shuttering
-
Shoring systems
-
Temporary support structures
It keeps props aligned and secure in any setup demanding accurate height control and high load strength.
Technical Specifications — Prop Sleeve
| Feature | Details |
|---|---|
| Material | Steel |
| Thread | MC 4 TPI |
| Tube Compatibility | 60.3mm OD Adjustable Props |
| Thickness Options | 2.9mm / 3.0mm / 3.2mm |
| Handle | 150mm × 12mm — Welded |
| Finish Options | Zinc Plated / Self Finish |
| Usage | Formwork, Shuttering, Scaffolding Support |
| Supply | Pan-India & Export-Ready Stock |
FAQ
Q1: Which prop size does it match?
It fits 60.3mm OD steel props, the standard size in the industry.
Q2: What threading does it use?
MC 4 TPI threading ensures quick adjustment and a strong grip.
Q3: Can I select thickness?
Yes. Pick 2.9mm, 3.0mm, or 3.2mm depending on the load.
Q4: Does it include a handle?
Yes. A welded handle makes tightening faster and easier.
Q5: What finish should I choose?
Go with Zinc Plated for better protection or Self Finish for site-level customization.
